ALUMTIG™ 200 AC DC TIG MMA Welder

  • Sale
  • Regular price $1,799.00
Same business day shipping on all orders placed before 10 am Melbourne Australia time. Please note because of COVID 19 your order may take longer to arrive than expected due to delays with carriers.


THE ULTIMATE SETUP

The welding power source is only part of the equation when it comes to producing high-quality welds. That's why the ALUMTIG comes with the best available including high flex gas-cooled cables, TIG torch flex heads, solid brass earth clamp and leading-edge non-mechanical proximity sensor foot pedal for the ultimate setup.




SETUP INCLUDES

  • 17 Series 8 Meter (26-ft) Flex head TIG torch with SWS BLUE-FLEX™ premium ultra-flexible cable high temp leather/NYLON sheath and remote amperage control.
  • 9/17 series 4 Meter foot pedal TIG torch SWS BLUE-FLEX™ ultra-flexible cable (17 Flex head included)
  • Pro TIG Torch kit including, 17 series 1.6mm and 2.4mm stubby gas lens kit, wedge collets, 2% Lanthanated tungstens, gas flow rate checker and back caps.
  • Foot pedal control
  • Side entry precision argon regulator with 2 Meter (6.5-ft) high temp braided quick connect gas hose
  • Professional solid brass croc jaw earth clamp with 4 Meter 25mm² (13-ft) SWS BLUE-FLEX™ cable
  • Quick Start Guide & TIG Welding guide (Paper copy of the operating manual is not included) Operating Manual
  • MMA Torch not included

    *Pricing and specifications subject to change without notice.







LATEST INVERTER TECHNOLOGY

Embedded microprocessor with the latest in German IGBT Infineon technology delivers ultimate durability and perfect welding characteristics day in day out.

NEXT-LEVEL DIGITAL DISPLAY

The durable large and bright LCD screen with intuitive programming tells you just what you need to know for ease of setup with the beginner in mind. The display also provides constant feedback on welding amps, welding modes such as foot pedal detection and vital stats such as overtemperature warnings and input power issues if they arise.


SMART PROGRAMMING

Featuring full digital control setting up and using the ALUMTIG is simple without compromise. EASY AC TIG, PRO DC TIG and PRO MMA welding modes take care of all the parameters for you with pre-configured settings for a professional weld every time. Turning on the pulse is as easy as setting the pulses per second from 0.1 - 2 Hz getting that penetration and filler rod consistency you have been after without even thinking about it. Along with the GAS purge function, weld timer that will tell you your total welding time and the ability to store up to 10 programs for customised user settings the ALUMTIG has all the features you could ever want and more. NOW with TACK CONTROL for that perfect tack every time!





FEATURES

Latest Inverter Technology
Embedded microprocessor with the latest in German IGBT Infineon technology delivers ultimate durability and perfect welding characteristics day in day out.



Revolutionary Digital Display
The durable large and bright LCD screen with intuitive programming tells you just what you need to know for ease of setup with the beginner in mind. The display also provides constant feedback on welding amps, welding modes such as foot pedal detection and vital stats such as overtemperature warnings and input power issues if they arise.



Smart Programming
Featuring full digital control setting up and using the ALUMTIG is simple without compromise. PRO AC TIG, PRO DC TIG and PRO MMA welding modes take care of all the parameters for you with pre-configured settings for a professional weld every time. Turning on the pulse is as easy as setting the pulses per second from 0.1 - 2 Hz getting that penetration and filler rod consistency you have been after without even thinking about it. Along with the GAS purge function, welding odometer that will tell you your total welding time and the ability to store up to 10 programs for customised user settings the ALUMTIG has all the features you could ever want and more.



AC Features
Advanced square wave with a wide balance and frequency range gives you the versatility for any Aluminium or Magnesium job.



Digital Pulse for AC and DC welding
When welding thin gauge materials and joints like thin sheet metal and outside corners pulse allows you to focus the arc increase travel speed and minimise warpage.



8 Meter Pro TIG Torch and Kit
The plug and play 8-metre 17 series flex head torch with ergonomic non-slip handle, amperage control (also includes quick-change momentary switch), stubby gas lens kit and high flex cables provide maximum control. And with a 35% duty cycle at 200 Amps it can handle most big jobs with ease.



4 Meter Pro TIG Torch and Kit
The plug and play 4-meter 17 series torch with flex head is perfect when using the foot control for precision work and the SWS BLUE-FLEX™ cable provides ultimate flexibility and reliability in the workshop.



Precision Foot Control
For those of you that like stepping on the gas the included foot pedal is as smooth as they get for ultimate puddle manipulation.



Stick Features (AC/DC)
With Hot Start, you will benefit by dealing with less stuck rods and arc Force giving you the capability to fine-tune the unit for specific fit-ups and electrodes such as 7018 and 6010.



VRD
For added safety when stick welding machine will operate with VRD (Voltage Reduction Device) and meets the requirements of Australian standards for on-site work.



Superior Duty Cycle
The duty cycle of 25% @ 200 Amps and 100% @ 100 Amps (40°C) handles all small to medium-sized jobs with ease. The duty cycle will increase as ambient temperature decreases 40% @ 200A (25°C)



Intelligent Heat Sensing Fan
Operates as needed to cool components and reduce airborne contaminants pulled through the power source while limiting noise pollution.



Thermal Overload Protection
The high-performance CPU continuously monitors vital component temperatures this significantly improves reliability so if you are welding for extended periods of time, and the duty limit cycle is reached the ALUMTIG™ 200 will let you know and stop current output while it performs it's cooling cycle.



Highly Portable
Dependable IGBT inverter technology ensures a highly portable and lightweight unit weighing only 11kg.



Robust Case
Drop-proof protection with eight individual impact points.



Generator Capable
The ALUMTIG™ 200 is safe to use with appropriate portable generators and will compensate for power fluctuations for a predictable arc.



The Best Warranty in The Business
We believe in our equipment, and we believe you should be able to enjoy welding without sweating the small stuff - that's why we've got your back. With a genuine 3 year warranty and 5 years extended on all power sources, you can weld confidently with the knowledge that we've got you covered.



Manufactured to the Highest Standards
Meets and exceeds the latest Australian, NZ and International electrical and electromagnetic compatibility standards. AS60974.1:2006, IEC60974.10, CE
